Servo-Mechanical Press Equipment Supplier

Aida Servo-Mechanical Press Equipment Supplier & DistributorServo Mechanical Press

TCR, Inc. specializes in providing a wide variety of servo-mechanical press machines manufactured by AIDA, a renowned global company with widespread production facilities across major markets. AIDA’s presence in the U.S. includes a sizable 177,600-square-foot manufacturing plant situated in Dayton, OH. This facility plays a crucial role in distributing press components and finished products throughout North America.

We offer an extensive range of AIDA servo-mechanical presses, catering to diverse industrial needs, with capacities ranging from 300 to 3,500 tons. Additionally, for unique and specific requirements, AIDA-Global can fulfill orders for presses with capabilities spanning from 35 to 3,500 tons. This wide range ensures that our customers can find the perfect servo-mechanical press machine to suit their production demands and preferences. Our partnership with AIDA guarantees top-notch quality and advanced technology in every press machine we offer, ensuring optimal performance and efficiency for our valued clients.

Servo-Mechanical Presses

What are a few types of Servo-Mechanical press equipment from AIDA?

DSF-C1 SINGLE POINT GAP FRAME PRESS

  • 80-, 110-, 150-, 200-, and 250-metric-ton models
  • SPM from 1 (all models) through 196 (DSF-C1-800)
  • Die height from 12.6” (DSF-C1-800) through 21.3” (DSF-C1-2500)
  • Bolster area (LR × FB) from 40.6” × 23.6” (DSF-C1-800) through 68.9” × 35.4” (DSF-C1-2500)
  • 80–250 metric ton capacity

DSF-N1 SINGLE POINT STRAIGHTSIDE PRESS

  • 80-, 110-, 150-, 200-, and 300-metric-ton models
  • SPM from 1 (all models) through 196 (DSF-N1-800)
  • Die height from 12.6” (DSF-N1-800) through 21.6” (DSF-N1- 3000)
  • Bolster area (LR × FB) from 35.4” × 23.6″ (DSF-N1-800) through  66.9” × 35.4” (DSF-N1-3000)
  • 80–300 metric ton capacity

DSF-N2 TWO POINT STRAIGHTSIDE PRESS

  • 110-, 160-, 200-, 250-, and 300-metric-ton models
  • SPM from 1 (all models) through 175 (DSF-N2-1100)
  • Die height from 15.7” (DSF-N2-1100) through 25.6” (DSF-N2- 3000)
  • Bolster area (LR × FB) from 65.4” × 26.8” (DSF-N2-1100) through 94.5” × 47.2” (DSF-N2-3000)
  • Uses HOLP to improve response times, provide adjustable trip levels, and free stuck slides
  • Industry-best tolerances in terms of drivetrain clearances
  • 110–300 metric ton capacity

DSF-M2 STRAIGHTSIDE SERVO PRESS

  • Available in single- and double-gear configurations
  • Highly programmable stroke and velocity profiles
  • High-torque/low-RPM servo motors
  • Uses the Aida ECO Servo Press Energy Management System to boost efficiency
  • 315–1,250 metric ton capacity
